Installing your Battery Doorbell

View/download PDF manual (English, Français, Deutsch, Italiano, Español, Nederlands, Dansk, Svenska, Suomi, Norsk, العربية)

Hardware included

Illustration of the Ring Battery Doorbell Installation Hardware A.

Tools included

Illustration of the Ring Battery Doorbell Push Pin Security Tool.

Tools needed

Illustration of a cross point screwdriver needed for installation.

PH2

Illustration of a power drill to use as an installation tool.

6 mm (¼ in)

1. Download the Ring app.

2. Scan the QR code.

3. Remove protective film.

4. Fully charge the battery.

Illustration of how to insert the charging cable to charge the Battery Doorbell.

5. Choose a location for your doorbell.

Illustration of a house with a battery doorbell installed at the recommended height of four feet.

Learn how to install a Wedge Kit or Corner Kit to angle your doorbell

Install your doorbell without connecting to an existing chime

6a. Install the mounting bracket. Then, attach your doorbell to the bracket.

Diagram showing different screws and drill needed for concrete, brick, and wood installation surfaces.Attaching mounting bracket to wall with screws and attaching doorbell to mounting bracket.

On stucco, brick, or concrete, use a 6 mm (¼ in) masonry bit to drill holes for the included wall anchors.

7a. Press until you hear a click to secure.

Illustration of a Battery Doorbell with an arrow to attach secure it to the mounting bracket.

Install your doorbell and connect to an existing chime

6b. Shut off power at the breaker.

Illustration on breaker box with one grey switch showing toggled off.

CAUTION! You’ll be working with electrical wires during the install process. If you are uncomfortable or inexperienced with doing so, consult with a licensed electrician. Do not wire your Ring Doorbell to a DC-powered intercom system.

For your safety, only use an existing doorbell transformer within the range specified below or compatible Ring accessories to power your device.

For connecting to an existing doorbell system: - Hardwired transformer (8 to 24 VAC, 50/60Hz, 5VA to 40VA)

Ring accessories are sold separately and may include: - Din Rail Transformer (24Vdc, 420mA) - Plug-In Adapter (24Vdc, 500mA)- Solar Charger (5.2Vdc, 100mA or 109mA) - Solar Panel (5Vdc, 380mA/480mA/800mA)

Using incompatible power sources can damage your device and cause electric shock.

7b. Install the mounting bracket. Then, connect your doorbell to existing wires and attach.

Diagram showing different screws and drill needed for concrete, brick, and wood installation surfaces.Attaching mounting bracket to wall with screws and attaching wires to doorbell and doorbell to mounting bracket.

On stucco, brick, or concrete, use a 6 mm (¼ in) masonry bit to drill holes for the included wall anchors.

8b. Press until you hear a click to secure.

Illustration of a Battery Doorbell with an arrow to attach secure it to the mounting bracket.

Remove your doorbell

Insert the removal tool to release the doorbell from the bracket.

Dismount the Ring Battery Doorbell with a Push Pin Security tool.
