Safety and compliance information for Ring Spotlight Cam Wired
Your Ring Spotlight Cam Wired device should only be used in accordance with the instructions and intended purpose. Using your Ring Spotlight Cam Wired in any way other than its intended purpose could cause injury to yourself, others or damage to the device.
SAFETY INFORMATION
FAILURE TO FOLLOW THESE SAFETY INSTRUCTIONS COULD RESULT IN FIRE, ELECTRIC SHOCK, OR OTHER INJURY OR DAMAGE.
WARNING: Electrical shock hazard! Always use caution when handling electrical wiring. Installation by a qualified electrician may be required in your area. Refer to your local laws and building regulations before performing electrical work; permits and/or professional installation may be required by law.
Your Ring Spotlight Cam Wired is not waterproof and as such should not be submerged in water, doing so could cause injury to yourself, others or damage to the device. For best performance, protect your Ring Spotlight Cam Wired from direct sunlight. When this device is plugged into an electrical socket-outlet, unplugging this device will disconnect it from the AC mains supply. Only plug this device into an easily accessible socket-outlet. Devices with a power cord must be located near the socket-outlet. Small parts contained in your device and its accessories may present a choking hazard to small children. Keep out of reach of small children.
PRODUCT SPECIFICATIONS
Device Name: Ring Spotlight Cam Wired
Model Number: 5L5C4T
Temperature Rating: -25 °C to 50 °C
Electrical Rating: 110-240V ~50/60Hz
Wireless Features:
• Single-Band wifi (2.4 GHz)
• Bluetooth
• Bluetooth Low Energy
Maximum Equivalent Isotropically Radiated Power:
• 2412 - 2472 MHz: 19.98 dBm EIRP
• 2402 - 2480 MHz: 8.49 dBm EIRP
This product contains a light source of energy efficiency class E.
DECLARATION OF CONFORMITY
Hereby, Ring LLC, declares that the radio equipment Ring Spot Light Cam Wired (5L5C4T) is in compliance with Directive 2014/53/EU and UK Radio Equipment Regulation, RER 2017 (S.I. 2017/1206), including currently valid amendment(s). The full texts of the declarations of conformity and other applicable statements of compliance for this product are available at the following internet address: www.ring.com/DoC
RADIO FREQUENCY COMPLIANCE
In order to protect human health, this device meets the thresholds for exposure of the general public to electromagnetic fields according to Council Recommendation 1999/519/EC. This device should be installed and operated with at least 20 cm between the radiator and your body.
RECYCLING YOUR DEVICE PROPERLY
In some areas, the disposal of certain electronic devices is regulated. Make sure you dispose of, or recycle, your device in accordance with your local laws and regulations. For information about recycling your device, go to amazon.com/devicesupport.
Click here to download the disassembly guide for recycling.Energy efficiency information
Supplier’s name or trade mark: Ring | |||
Supplier’s address: Ring, 1 Principal Place, Worship Street, London, EC2A 2FA | |||
Model identifier: 5L5C4T | |||
Type of light source: | |||
Lighting technology used: | LED | Non-directional or directional: | NDLS |
Light source cap-type (or other electric interface) | Soldered | ||
Mains or non-mains: | MLS | Connected light source (CLS): | No |
Colour-tuneable light source: | No | Envelope: | No |
High luminance light source: | No | ||
Anti-glare shield: | Yes | Dimmable: | Yes |
General product parameters | |||
Energy consumption in on-mode (kWh/1,000 h) rounded up to the nearest integer | 6 | Energy efficiency class | E |
Useful luminous flux (Φuse), indicating if it refers to the flux in a sphere (360°), in a wide cone (120°) or in a narrow cone (90°) | 754 in sphere | Correlated colour temperature, rounded to the nearest 100K, or the range of correlated colour temperatures, rounded to the nearest 100K, that can be set | 5000K |
On-mode power (Pon), expressed in W | 6.1 | Standby power (Psb), expressed in W and rounded to the second decimal point | 0.13 |
Networked standby power (Pnet) for CLS, expressed in W and rounded to the second decimal point | N/A | Colour rendering index, rounded to the nearest integer, or the range of CRI-values that can be set | 100 |
Outer dimensions without separate control gear, lighting control parts and non-lighting control parts, if any (millimetre) | Height | 126 | |
Width | 69 | ||
Depth | 76 | ||
Chromaticity coordinates (x and y) | X: 0.341 Y: 0.351 | ||
Parameters for directional light sources: | |||
Peak luminous intensity (cd) | N/A | Beam angle in degrees, or the range of beam angles that can be set | 103 |
Parameters for LED and OLED light sources: | |||
R9 colour rendering index value | N/A | Survival factor | - |
The lumen maintenance factor | - | ||
Parameters for LED and OLED mains light sources: | |||
Displacement factor (cos φ1) | 0.75 | Colour consistency in McAdam ellipses | 2 |
Flicker metric (Pst LM) | 0 | Stroboscopic effect metric (SVM) | 0 |
Spectral power distribution in the range 250 nm to 800 nm, at full-load
